Product benefits
LED Chip provided by SAMSUNG
White, Natural and Warm White light color options
Available from 30W up to 300W
Premium quality Aluminium body
Corrosion Resistant
Fascia glass sealed with silicone rubber ensuring superior waterproof / airtight performance
Built in constant current driver
Built in Power supply, No external ballast required
Applications
Driveways
Gardens
Bill Boards
Sports Grounds
Parking Lots etc.

Specifications

General Information
LED Chip
SMD
Lifespan
30000 hrs

Electrical Data
Wattage
20W
Voltage
AC: 220-240V
Frequency
50Hz
Power Factor
>0.7

Light technical data
Light color
Natural White
Color Temperature
4000K
Luminous flux (lm)
1600 lm
Color Rendering Index CRI
>80
Beam angle°
100°

Body details
Material
Die cast aluminum
Body Colour
Black

Capabilities
Dimmable
No
Detection Range
120 °
Detection Distance
2-8m
Time Delay
Мin. 12sec ±3sec; Max. 6min ±2min.
Starting Time 100% ON
0.001 sec (instant on)
Color stability
<6
Luminous intensity, Cd
712.87 Cd Max.
On/Off cycles
>15000
Working conditions
Not suitable for use in extreme conditions. Normal working conditions is -20° +45°
IP Rating
IP65

Dimensions
Size
211 x 185 x 50 mm
Wire Length
1m.
Mounting Size
Height: 1.8 - 2.5m

Product Data
Order code
452
Product code
VT-20-S
Items per pack
1
Item Weight
0,58
Item Volume
0,00204
Items per box
20
EAN Code
3800157631082

Certificates & standards
Energy efficiency class
A++
Certification
CE, EMC, ROHS

Additional
Brand
V-TAC
Warranty
5 years
